Vortex Generators are located at the base of the Valor lightbar. Vortex Generators are designed to improve the aerodynamic surface and efficiently direct passing air to reduce subsequent drag on the rear of the vehicle. The result is better fuel efficiency and a reduction in wind noise.
Full-sized Image
Federal Signal’s patented ROC technology is built to eliminate approximately 85% of the connection failure points found in a typical lightbar. Wires, connections, and assemblies have been replaced by PCB assemblies — reducing labor repair time and increasing the road time for emergency vehicles.
Full-sized Image
Full-sized Image
Valor® Emergency Vehicle Light Bar
- Unique low-profile, non-linear, V-shape light bar
- Available in 44" and 51" lengths
- Amber, Blue, Green, Red, and White
- Single-, dual-, and tri-color capability
- SignalMaster™ directional warning available
- Left-flood, right-flood, full-flood, takedowns, alley lights, and S/T/T available
- Low-power mode
- (27) flash patterns
- 12 Vdc
- Integrated Vortex™ generators for increased fuel efficiency and reduced wind noise
- Can be serviced without removal from the vehicle roof
- Optional quick-disconnect for easy service removal from vehicle
- Optional HotFoot® mounting for additional alley and takedown lights
- Five-year warranty
Features
Valor® light bar by Federal Signal is a high-performance, non-linear LED light bar for emergency vehicles that provides 360-degree light output and superior off-axis lighting for police, fire, and other emergency vehicles. The LED light bar’s v-shape, low-profile design enhance off-axis illumination warning capability. The Valor light bar unique shape and and patented Solaris® LED reflector technology maximizes the LED light source, eliminates dark spots, and improves visibility on the road and while clearing a path through intersections.
The Valor® LED light bar also features exclusive SpectraLux® multi-color LED technology, enabling each LED module to change colors during operation. The versatility of the SpectraLux® technology allows the multi-color light bar to operate with up to three colors per module, flashing one color and then overriding to a front or rear flood light or a rear SignalMaster™ directional warning pattern.
Programming the Valor® emergency vehicle light bar is straightforward with the Pathfinder® light/siren controller and the Convergence Network Configuration Software. With FSJoin, multiple warning devices can be synchronized for cohesive vehicle solutions. Installation is straightforward with a “plug-and-play” setup via standard RJ45 connections. The Valor® features Reliable Onboard Circuitry (ROC) technology, which eliminates potential failure points by replacing traditional wires and connectors with PCB assemblies, decreasing repair time and increasing operational efficiency.
For police and fire departments that rank safety as a top priority and desire a low-profile appearance, the Valor® emergency vehicle light bar is the obvious choice.
FS Technologies
SKU Specifications
| SKU | Operating Current | Max Current | Standby Current | Input Voltage | Operating Temperature | Number of Flash Patterns | LED Count | LED Colors | Dome Colors | Harness/Connection Type | Harness Length | Mount | Approvals | Color Option | Length | Width | Height | Ship Weight (lb) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| VALR51J-PF3AL | 14.0 A @ 12 Vdc / 16.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Red/Blue/White | Clear | Serial | 23" | Low Hook | CCR Title 13,IP65 | Tri-Color | 51.3 in (130.3 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 43.20 |
| VALR51J-F2H | 14.0 A @ 12 Vdc / 16.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Red/White | Clear | Serial | 23" | Hook | CCR Title 13,IP65 | Dual-color | 51.3 in (130.3 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 43.20 |
| VALR44J-PF3AL | 12.0 A @ 12 Vdc / 14.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Red/Blue/White | Clear | Serial | 23" | Low Hook | CCR Title 13,IP65 | Tri-Color | 43.7 in (111.0 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 39.30 |
| VALR44J-F2H | 12.0 A @ 12 Vdc / 14.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Red/White | Clear | Serial | 23" | Hook | CCR Title 13,IP65 | Dual-color | 43.7 in (111.0 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 39.30 |
| VALR44J-P2BL | 12.0 A @ 12 Vdc / 14.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Blue/White | Clear | Serial | 23" | Low Hook | CCR Title 13,IP65 | Tri-Color | 43.7 in (111.0 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 39.30 |
| VALR44J-P1BL | 12.0 A @ 12 Vdc / 14.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Red/Blue/White | Clear | Serial | 23" | Low Hook | CCR Title 13,IP65 | Tri-Color | 43.7 in (111.0 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 39.30 |
| VALR44J-P1BH | 12.0 A @ 12 Vdc / 14.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Red/Blue/White | Clear | Serial | 23" | Hook | CCR Title 13,IP65 | Tri-Color | 43.7 in (111.0 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 39.30 |
| VALR51J-P2BL | 14.0 A @ 12 Vdc / 16.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Blue/White | Clear | Serial | 23" | Low Hook | CCR Title 13,IP65 | Tri-Color | 51.3 in (130.3 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 43.20 |
| VALR51J-P1BH | 14.0 A @ 12 Vdc / 16.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Red/Blue/White | Clear | Serial | 23" | Hook | CCR Title 13,IP65 | Tri-Color | 51.3 in (130.3 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 43.20 |
| VALR51J-P1BL | 14.0 A @ 12 Vdc / 16.0 A @ 12 Vdc with HotFoot | N/A | N/A | N/A | -40˚ to +149˚ F (-40˚ to +65˚ C) | 27 | N/A | Red/Blue/White | Clear | Serial | 23" | Low Hook | CCR Title 13,IP65 | Tri-Color | 51.3 in (130.3 cm) | 19.8 in (50.4 cm) | 1.96 in (5.0 cm) | 43.20 |
