Reliant™ S2 Light Bar

  • Ultra low-profile, linear light bar
  • Available in 48" length
  • Amber, Blue, Green, Red, and White
  • Single-, dual-, and tri-color capability
  • Built-in SignalMaster™ directional warning
  • Front flood, rear flood, left flood, right flood, takedowns, alley lights, work lights, and OBDII-integrated S/T/T available
  • Low-power mode
  • (28) flash patterns
  • 12 Vdc
  • Five-year warranty

Features

The Reliant™ S2 light bar features a low-profile, linear design that provides a superior multi-color warning on vehicular applications. Designed with safety in mind, Reliant S2 is packed with exclusive technologies and comes with various standard functions to cover all your basic needs at a budget-friendly price. Reliant S2 includes (28) flash patterns, built-in SignalMaster™, and alley, takedown, brake, and flood light capabilities to keep emergency personnel safe on the road. The Reliant S2 comes standard with a pre-curved extrusion to ensure the light bar does not bow.


SpectraLux® Lights The Way

Exclusive to Federal Signal, the SpectraLux® multi-color LED technology allows an LED light source to change color while in operation. In each module of the light bar, through user-selected flash patterns, the LEDs can change between Amber, Blue, Red, and White (up to 3 in each module).


Solaris® and ROC (Reliable Onboard Circuitry™ )

Built with Solaris® LED reflector technology, the Reliant S2 light bar is engineered to increase off-axis warning and maximize the LED light source to eliminate dark spots and increase visibility while on the road. ROC technology minimizes potential failure points in the light bar — replacing wires, connectors, and assemblies with PCB assemblies to reduce labor repair time and increase road time for public safety personnel.


FS Convergence Network

For maximum performance, the FS Convergence Network provides “plug-n-play” installation. Utilizing the RJ45 connections, the Reliant S2 can be easily programmed using a Convergence Network siren or controller. A serial interface module (ordered separately) with your existing light controller can also be used to program and operate the features and functions of the Reliant S2.

FS Technologies

SKU Specifications

SKUOperating CurrentMax CurrentStandby CurrentInput VoltageOperating TemperatureNumber of Flash PatternsLED CountLED ColorsDome ColorsHarness/Connection TypeHarness LengthMount ApprovalsColor OptionLengthWidthHeightShip Weight (lb)
RLNT48-P4LC9 A @ 50% duty cycleN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/AN/AClearSerialN/AN/AN/AN/A47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48-P2LC9 A @ 50% duty cycleN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/AN/AN/ASerialN/AN/AN/AN/A47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48-P3LC9 A @ 50% duty cycleN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/AN/AN/ASerialN/AN/AN/AN/A47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48-P1LC9 A @ 50% duty cycleN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/AN/AN/ASerialN/AN/AN/AN/A47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48-P4LB9 A @ 50% duty cycleN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/AN/AN/ASerialN/AN/AN/AN/A47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48-P2LB9 A @ 50% duty cycleN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/AN/AN/ASerialN/AN/AN/AN/A47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48-P3LRB9 A @ 50% duty cycleN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/AN/AN/ASerialN/AN/AN/AN/A47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48-P1LRB9 A @ 50% duty cycleN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/AN/AN/ASerialN/AN/AN/AN/A47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48J-02RR8.5 A @ 12 VdcN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/ARed/Blue/WhiteRedSerialN/ALow HookCCR Title 13,IP69KTri-Color47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48J-02CC8.5 A @ 12 VdcN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/ARed/Blue/WhiteClearSerialN/ALow HookCCR Title 13,IP69KTri-Color47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48J-01CC8.5 A @ 12 VdcN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/ARed/Blue/WhiteClearSerialN/ALow HookCCR Title 13,IP69KTri-Color47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50
RLNT48J-01RR8.5 A @ 12 VdcN/AN/AN/A-40˚ to +149˚F (-40˚ to +65˚C)28N/ARed/Blue/WhiteRedSerialN/ALow HookCCR Title 13,IP69KTri-Color47.6 in (120.9 cm)11.6 in (29.5 cm)1.3 in (3.3 cm)20.50

Videos

Reliant S2 Lightbar Video

Product #Description
605012Two-channel relay module; (2) 7.5 A outputs
660100SSG
