FedSig's AV1-LED Flashing Combination Audible/Visual Signal features an orange LED warning light mounted on a black base, with red and black wires attached.

The AV1-LED Flashing Combination Audible/Visual Signal by FedSig is a blue LED audiovisual signal light featuring a black base with wires extending from the side.

A FedSig AV1-LED Flashing Combination Audible/Visual Signal featuring a cylindrical shape, ribbed clear lens, and two connecting wires, mounted on a black base with a label.

AV1-LED Flashing Combination Audible/Visual Signal by FedSig, featuring a green LED warning light with a black base and exposed wires. The model number and specifications label are clearly visible.

AV1-LED Flashing Combination Audible/Visual Signal by FedSig featuring a red warning light with a black base and visible wiring.

AV1-LED Flashing Combination Audible/Visual Signals

Available in 24 Vdc and 120 Vac
Five lamp/lens colors: Amber, Blue, Clear, Green and Red
50,000-hour LED
Surface, integrated 1/2-inch NPT pipe, and 4-inch electrical box mount
Twist-off lens for easy access
Internal buzzer produces 85 dBA at 10' (95 dBA at 1m)
Flexible operation allows the unit to independently flash without buzzer
PLC compatible
Type 3R enclosure
UL and cUL Listed

Where to Buy Request Information

Features
SKU Specifications
Accessories

Features

The model AV1-LED warning light is a combination audible/visual signal. The warning light also features a 100% polycarbonate housing that is rated for Type 3R rain-tight applications.

All AV1-LED alert light units feature a twist-and-lock lens design to allow for tool-free access to the LED. The Fresnel lens provides superior visibility in all directions.

The integrated buzzer provides 85 dBa output @ 10 feet (95 dBa @ 1M). The unit can operate in two ways: flashing/buzzer combination or flashing only. The LED flash pattern can be field adjusted to 60 FPM or 75 FPM, via a jumper on the PC board.

Each unit is factory-assembled with two color-coded leads. If desired, the user can remove the leads and connect directly to the terminal block located at the base of the unit.
